Wax melters with steam generators
In this category you will find beeswax melters with a steam generator, designed for efficient wax melting using hot steam. The melters are made of stainless steel and heated electrically – the water is brought to the boiling point, and the resulting steam passes through a perforated basket, where it reliably melts the wax. The clean wax drains into a mold, while impurities remain in the basket. Some models are additionally equipped with a press for faster beeswax extraction, or they can also be used for disinfection purposes. The steam generator has an output of approximately 2 kW, and if required, multiple units can be used.
Beeswax Melters with a Steam Generator
Rendering beeswax is an inseparable part of running any apiary—whether you are processing cappings after uncapping, rotating out old combs, or disposing of leftover comb material after the season. Beeswax melters with a steam generator (steam wax melters) turn this task into a clean, fast, and well-controlled process. Thanks to the power of hot steam, you obtain high-quality wax with a high yield, often without the need for labor‑intensive cutting of combs out of frames.
How a Steam Wax Melter Works
The principle is simple and proven: the steam generator heats water to produce steam, which is fed through a hose into the closed chamber of the melter. The steam quickly heats the inserted material (frames, combs, wax scraps, or cappings), the wax is released, melts, and flows through a sieve / filter insert into a collection container. Solid residues (cocoons, propolis, sludge) remain inside.
-
Steam generator: an electric steam unit that ensures a stable supply of steam and rapid temperature build-up.
-
Melter container: the melting vessel (often stainless steel or durable plastic) with space for frames or a wax insert and a wax outlet.
What You Can Most Commonly Render in a Steam Melter
Steam wax melters are versatile and in practice cover most “wax materials” produced in an apiary:
-
cappings (uncapping wax) – usually the highest-quality raw material,
-
old combs and brood comb from frame replacement,
-
comb remnants and foundation frames,
-
wax cuttings and residues from routine beekeeping work.
If you want the resulting wax to be truly light yellow and as clean as possible, it pays to sort the raw material—for example, melt cappings separately and process old, dark combs on their own.
Main Advantages of Steam Wax Melters
Time Savings and Less Messy Work
With many models, entire frames can be inserted, eliminating time-consuming cutting of combs. Steam works quickly, evenly, and independently of weather conditions (unlike solar wax melters).
High Yield and Gentle Melting
Hot steam penetrates the comb structure and releases wax even from denser, older combs. When used correctly, the wax does not overheat or scorch and is often suitable for further processing after the first melt.
Hygiene and Thermal Sanitation
Steam helps reduce the presence of pests (e.g. wax moths) and generally improves hygiene. Frames after melting are often “cleaner” and ready for further use (depending on the melter design and loading method).
Material Design: Stainless Steel vs. Plastic
Stainless Steel Wax Melters
Stainless steel is the choice for beekeepers who want long service life, durability, and easy maintenance. A quality stainless steel melter is easy to clean, withstands intensive use, and is suitable for larger numbers of frames and regular wax rendering throughout the season.
Plastic Wax Melters
A lightweight and more affordable option for smaller operations and beginner beekeepers. When used correctly, they offer very decent melting efficiency, easy handling, and quick setup.
How to Choose the Right Steam Wax Melter
When choosing, consider primarily how many colonies you manage and how often you rotate combs. Important factors also include frame size and whether you want to melt whole frames or only cut-out comb.
-
Capacity (number of frames): for a small apiary, smaller containers are usually sufficient; larger operations benefit from higher capacity to speed up work.
-
Steam generator output: affects heat-up time and smooth melting, especially with larger volumes of comb.
-
Filtration and drainage: a quality sieve and well-designed wax outlet make cleaning easier and improve results.
-
Construction and safety: stable lid, reliable hose connection, safe water refilling.
Recommended Melting Procedure
-
Prepare the material: sort cappings and combs, and remove frames as required by the melter type.
-
Fill the steam generator with water: follow the recommended level and ensure the water does not boil dry during operation.
-
Start steam generation: wax begins to flow into the collection container while impurities remain inside.
-
Allow the wax to solidify: after cooling, the wax “cake” usually separates from the bottom layer of sludge.
-
Refine if necessary: for higher quality, remelt the wax and strain it through a finer filter or cloth.
Maintenance and Safe Operation
Working with steam involves high temperatures and steam pressure in the hose—therefore, always prioritize safety and regularly inspect the setup. Pay special attention to the steam generator, which may suffer from limescale buildup when using hard water.
-
Work on a stable, non-flammable surface and keep the equipment out of reach of children.
-
Use protective gloves and ideally eye protection.
-
Check hoses, connections, and seals—steam leaks are dangerous.
-
To prevent limescale, use distilled water or perform regular descaling (e.g. with citric acid, according to the instructions).
-
After work, allow the unit to cool down, clean the sieves/baskets, and dry the internal parts.
Our tip: For even more convenient wax processing, useful accessories include wax molds, clarification containers, and filter inserts. These help you obtain cleaner wax and uniform blocks for further use.
Frequently Asked Questions
- Is a steam wax melter suitable for small amounts of wax?
-
Yes. With smaller quantities, you will especially appreciate the cleanliness and comfort of the process. However, steam melters are most cost-effective when used regularly during the season and when processing larger amounts of comb.
- Can I melt whole frames without cutting out the comb?
-
With many models, yes—but it always depends on the design and dimensions of the container. Before purchasing, check which frame sizes the melter supports and whether it is intended for whole frames.
- How do I know if the wax is clean enough?
-
After solidification, inspect the underside of the wax block. If it is heavily contaminated with sludge, a second melting and finer filtration will help. For top-quality results, melt cappings separately from old comb.
Choose a Solution Based on the Size of Your Apiary
Whether you are a hobby beekeeper or run a larger apiary, a steam wax melter helps you extract the maximum amount of wax with minimal effort. Browse the selection and choose the capacity and design that best match your number of colonies and your comb management practices.
