Separators and Wax Centrifuges

Separators and Centrifuges: Modern Equipment for Processing Bee Products

Beekeeping is a traditional craft that continues to evolve thanks to modern technology. Today’s beekeepers have access to a variety of advanced devices that help them optimize the processes involved in honey and beeswax production and processing. Among these innovations are multifunctional machines that combine several features, making work easier and increasing efficiency. In this article, we will look at some of these devices and their benefits for beekeepers.

Wax separators and centrifuges are essential tools for honey extraction, utilizing high-speed rotation to separate honey from wax. These machines efficiently remove cappings from honey, contributing to maximum yield. The wax separator is particularly useful during seasons with a high presence of honeydew honey, which can be very hard and difficult to extract using traditional honey extractors. This separator uses circulating warm air to separate honey from wax. An air heater with an adjustable thermostat (30–110 °C) is integrated into the lid, while a fan ensures even heat distribution throughout the tank. This allows for the efficient melting of wax cappings and the dripping of honey to the bottom of the tank, where it is protected from overheating by the layer of melted wax. Additionally, the separator can be used for liquefying crystallized honey. Place honey jars or buckets on the drip tray and set the thermostat to 40 °C. For honeydew honey, we recommend adding as many wax foundations as possible to colonies, which bees quickly build upon. You can then easily harvest both wax and honey from the removed combs. The sand crystals remain intact, ensuring pure honey and wax. The separator is ideal for beekeeping operations that use uncapping machines or knives.

Separator: Combining Wax Melting and Honey Separation

The 2-in-1 separator is a modern machine that merges two essential functions – wax melting and honey separation. This multipurpose device enables beekeepers to make full use of all bee products, even in challenging seasonal weather. Thanks to its perforated shaftless basket and rotation similar to a honey extractor, it can easily separate honey from combs. After honey extraction, beekeepers can effortlessly transition to melting old combs or wild burr combs.

The machine is constructed from acid-resistant stainless steel, guaranteeing a long service life and high-quality wax. Wax melting takes place in a separate water tank, ensuring efficient extraction regardless of the wax’s origin. Automatic shut-off in case of low water level adds further convenience in operation.

Separator: The Key to Pure Honey

The separator guarantees perfectly clean honey thanks to a precise filtration process after honey is separated from comb. The device, made entirely of acid-resistant stainless steel, features a transparent plexiglass cover, which allows you to observe the filtration process and prevents any unwanted particles from entering the tank.

Technological parameters include a powerful motor with adjustable speed and magnetic lid lock, which increase efficiency and make the device user-friendly. With a maximum capacity of up to 150 kg/h, this separator is a major asset for processing larger quantities of honey.

Separators represent a further revolution in wax processing, combining advanced technology with user comfort. These machines operate using a hot-air circulation system, ensuring even temperature distribution and efficient separation of wax from honey.

Specially designed for frames of all sizes, these devices can also liquefy crystallized honey, further broadening their usefulness. The insulated double-walled stainless steel tank, integrated fan, and sloped bottom provide safe and reliable operation, ensuring quality honey with minimal energy loss.

Multifunctional uses:

• Wax melting and honey separation.

• Liquefying crystallized honey.

• Preheating frames before waxing.

By correctly setting temperature parameters (40 °C at the bottom and 80 °C in the lid), the separator offers nearly 100% honey yield, providing a quick return on investment.

The machine also allows for thermostatic temperature control between 30–110 °C, eliminating the risk of overheating the honey and preserving its quality.

How Separators Work

A separator solves the challenge of separating honey from wax by using warm air to heat the cappings. This process lowers the viscosity of honey, making it easier for the honey to drip down to the bottom of the tank. When the temperature is increased further, the wax melts, slowly running down and forming a separating layer above the honey.

Such equipment is particularly valuable for larger beekeeping operations that process substantial amounts of cappings. However, if you have only a few hives, you might consider home alternatives, such as adapting a convection oven with a fan as an improvised separator.

Solutions Using Common Kitchen Equipment

If you have access to a convection oven with a fan and heating element, you can create your own separator. You will need a plastic honey tank, a stainless steel sieve for dripping cappings, and an insert for stable placement of the thermal cover on the tank. This method is cost-effective and suitable for beekeepers looking for alternatives to professional equipment.

Professional Equipment

For beekeepers with larger operations, there are more sophisticated options such as screw-type separators or centrifuges, which can separate honey and wax more efficiently through automated processes. The use of a screw press for extracting cappings is ideal for beekeepers dealing with large volumes and seeking efficient extraction methods.
